Description
The Comprehensive Cat 6 500 MHz UTP Stranded Cable (1000′, Black) features 4 unshielded twisted pairs made of 24 AWG stranded bare copper. With a UL/NEC CMR/MPR rating, it adheres to TIA standards 568 and 570 for optimal performance.
Additional information
| Weight | 29 lbs |
|---|---|
| Dimensions | 16 × 14.7 × 8.9 in |
| Conductors | 4 twisted pairs 24 AWG stranded bare copper cable |
| Bandwidth | Supports voice/data/video distribution applications up to 550 MHz |
| Standards | Meets all Cat 6 TIA/EIA standards, verified to EIA/TIA 568B.2 |
| Conductor DC Resistance | 9.8 ohm at 328.08' (100 m) maximum |
| Outer Diameter | 0.24" (6.2 mm) |
| UL Rating | CMR/MPR |
| Jacket | PVC |
| Outer Jacket Color | Black |
| RoHS Compliant | Yes |
| Cable Length | 1000' (304.8 m) |
